1. DIRECT MONITOR Illuminated Button
Note: the
DIRECT MONITOR switch is disabled when using the BMπHP as a standalone
guitar pedal. In this case, the audio output is always sent to the stereo output
jacks and Headphone output.
2. Headphone LVL Knob Controls the volume level at the Headphone output
3. USB STATUS LED
4. USB GAIN Knob Controls the signal level of the audio sent to the computer
- 4 -
Hardware Overview
Front Panel Controls
12 4 5
6
13
8
10
11
14
15
16
17
12
9
7
3
