Electro-Harmonix Super Switcher - NOTES AND SPECIFICATIONS

2
TABLE OF CONTENTS
Notes and Specifications 2
Controls and Connections 3
Ins, Outs, Sends and Returns 3
Illuminated Buttons 4
Footswitches and LEDs 4
Boost and Value Knobs 5
Preset Mode 6
Instant Access Mode 7
Control Functions 8
MIDI Control 9
MIDI Receive Message Tables 11
Setup Menu 12
Restoring Factory Settings 15
Warranty Information and Compliance 16
NOTES AND SPECIFICATIONS
 Audio input impedance: 2Mbufferorboostonly
 Audio output impedance for each output: 470bufferonly
 Audio output impedance for each output: 1Kbooston
 Current draw: 150mA
 Maximum input signal level: +11 dBu
 Bypass: Mechanical relay true bypass switching
