UHF Wireless RE3-RX receiver | en 21
-Voice Installation manual 2018-12 | 01 |
15 Antenna B jack
BNC RF jack to attach either a supplied half-wave whip antenna, or
antenna extension coax cable connected to a front-mounted or remote
extension antenna. This jack also supplies 12 volts DC booster feed to
power in-line RF amplifiers or active antennas when antenna power is
set to on (factory default). The RE3 diversity receiver requires
connecting antennas to both antenna jacks.
16 DC power jack
Connection point for receiver’s external power supply. This is where a
DC distribution lead connects when using the optional AASP antenna
splitter.
