UHF Wireless RE3-BPT bodypack transmitter | en 43
-Voice Installation manual 2018-12 | 01 |
three seconds when the transmitter is successfully sync’d to the
receiver.
5 Power button
This is a multi-purpose button, functioning as a power on and off
switch, as well as a menu escape switch.
To power ON transmitter: press briefly.
To power OFF transmitter: press and hold for three seconds.
Transmitter turns off.
While in parameter edit mode, press to escape to home screen.
CANCEL appears on the screen and no setting changes are saved.
6
Battery door
latch/lock
Slide the latch downward to unlock the battery door. Continue pressing
the latch downward while rotating the bottom-hinged door downward to
open the battery compartment door.
Covers and protects batteries.
8
compartment
Holds two AA or AA-size rechargeable cells. Install AA cells according
to polarity orientation as shown.
9 SET button
The most commonly used menu navigation button, it is a multi-purpose
action button which functions as an enter key, a menu advance key,
and a save or store key.
10
▲ (up button)
This menu navigation button adjusts the value of an editable
parameter. Pressing the ▲ button will increase the displayed value of
the current parameter, or the next state condition value above the
displayed state value.
11
▼ (down button)
This menu navigation button adjusts the value of an editable
parameter. Pressing the ▼ button will decrease the displayed value of
the current parameter, or the next state condition value below the
displayed state value.
12 Mute switch
This toggle switch engages mute / unmute function, and the colored
LED indicates statuses. Sliding the illuminated switch into the mute
position silences the audio. Sliding the illuminated switch away from
mute position makes audio live. LED color indicators:
ON = solid green. Mute = flashing red. Low battery = solid red.
13
Charging contact
(one)
Three charging contacts, one to the left side and two on the right are
for use when using the optional BC2 battery charger and rechargeable
cells.
14
Charging contacts
(two)
Three charging contacts, one to the left side and two on the right are
for use when using the optional BC2 battery charger and rechargeable
cells.
15 4-pin mini jack
This is the audio input jack where the audio input device (lavalier or
headworn microphone, or instrument cable) connects to the
transmitter.
