Electro-Voice RE3 Series Installation Manual

58
en |
Technical data
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
12 Technical data
RE3-RX receiver
Frequency Oscillation Mode:
Phase-locked loop (PLL)
Carrier Frequency Range:
470 - 865 MHz
(tuning bandwid
th is band dependent)
Band Names
Tuning Bandwidths and Carrier
Frequency Ranges
5L: 36 MHz (488-524 MHz)
5H:
36 MHz (560-596 MHz)
6M:
10 MHz (653-663 MHz)
T:
3 MHz (803-806 MHz)
8M:
(823-865 MHz)
8M is split into two segments:
9 MHz (823-832 MHz)
2 MHz (863-865 MHz)
Sync Frequency:
Ultrasonic 40 kHz
Diversity:
Antenna diversity
Bandwidth:
36MHz
Signal/Noise Ratio:
>100dB(A)
Total Harmonic Distortion (Thd):
<0.6%@1kHz
Receiving Sensitivity:
-81dBm for -12dB SINAD
Frequency Response:
63Hz~16kHz±2dB (BPT)
51Hz~1tkHz±2dB (HHT)
Antenna Type:
Detachable ½ wave with BNC connector
Antenna Booster Power:
DC12 - 15V/100mA
Function Display By:
LCD
Contents Of
Display:
Group, channel, frequency, antenna A/B, transmitter battery
level, transmitter status (mute, live, or no sync), output level
attenuation, AF indication, RF indication, key lock indicator.
Control Functions:
Power, scan, frequency, group, channel, squelch, TX
sensitivity, TX attenuation, TX RF power, TX auto off, TX key
lock, TX display info, TX sync configuration, RX output
volume, RX output level, RX antenna booster power, RX key
lock, RX display contrast, RX display brightness, RX system
reset.
Sync Data Options:
Frequency, group, channel, sensitivity level, attenuation
status, RF power, auto off status, key lock status, transmitter
display (freq or Gp/Ch)
Audio Frequency Output Level:
¼” (6.3mm) Phone Jack
：
-10dBV
XLR Jack
: -4dBV (Line) & -24dBV (MIC)
Audio Frequency Output
Impedance:
240Ω (unbalanced)
1400
Ω (balanced)
