Electro-Voice RE3 Series Installation Manual

RE3
UHF Wireless Technical data | en 59
Electro
-Voice Installation manual 2018-12 | 01 |
F.01U.362.808
Squelch and noise muting:
Noise muting and tone code locking
Output Ports:
1 x balanced XLRM jack
1 x unbalanced ¼” TS (6.3mm) jack
Power Supply:
DC12~15V/500mA
Finish:
Black polyurethane paint
Dimensions:
Width: 8.27 inch (210mm)
Height: (with feet attached) 1.85 inch (47mm)
Height: (without feet attached) 1.73 inch (44mm)
Depth: (including antenna jack) 6.89 inch (175mm)
Depth: (not including antenna jack) 6.1 inch
(155mm)
RE3-HHT handheld transmitter
Frequency Oscillation Mode:
Phase-locked loop (PLL)
Band Names
Tuning Bandwidths and Carrier
Frequency Ranges
5L: 36 MHz (488-524 MHz)
5H:
36 MHz (560-596 MHz)
6M:
10 MHz (653-663 MHz)
T:
3 MHz (803-806 MHz)
8M:
(823-865 MHz)
8M is split into two segments:
9 MHz (823-832 MHz)
2 MHz (863-865 MHz)
Sync Frequency:
Ultrasonic
RF Power Output:
Frequency band specific as shown below
5L
(488-524MHz): Low 10mW / High 50mW
5H
(560-596MHz): Low 10mW / High 50mW
6M
(653-663MHz): Low 10mW / High 20mW
T
(803-806MHz): Low 10mW / High 50mW
8M
(823-865MHz): 10mW
Display By:
LCD + LED
Function Controls:
Power, mute, group, channel, frequency, sensitivity
adjustment, RF power, auto off, key
lock.
RF Stability:
<±10kHz@Fc
Modulation Frequency Shift:
Wideband FM
±48kHz deviation
Harmonic Radiation:
<-50dBc
Battery:
2 x AA alkaline battery or NiMH rechargeable battery
Charging Contacts:
Yes
Microphone Head Coupling:
1.25” diameter, 28 UN-2A thread pitch
Microphone Electrical Contact:
3-ring/3-pin
Finish:
Black polyurethane paint
