Electro-Voice RE3 Series Installation Manual

60
en |
Technical data
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
Dimensions (without head):
Height: 7.52 inch (191mm)
Width at threaded end: 1.46 inch (37mm)
Width at control cover: 0.856 inch (22mm)
RE3-BPT bodypack transmitter
Frequency Oscillation Mode:
Phase-locked loop (PLL)
Band Names:
Tuning Bandwidths and Carrier
Frequency Ranges:
5L: 36 MHz (488-524 MHz)
5H:
36 MHz (560-596 MHz)
6M:
10 MHz (653-663 MHz)
T:
3 MHz (803-806 MHz)
8M:
(823-865 MHz)
8M is split into two segments:
9 MHz (823-832 MHz)
2 MHz (863-865 MHz)
Sync Frequency:
Ultrasonic
RF Power Output:
Frequency band specific as shown below
5L
(488-524MHz): Low 10mW / High 50mW
5H
(560-596MHz): Low 10mW / High 50mW
6M
(653-663MHz): Low 10mW / High 20mW
T
(803-806MHz): Low 10mW / High 50mW
8M
(823-865MHz): 10mW
Display By:
LCD + LED
Function Controls:
Power, mute, group, channel, frequency, sensitivity
adjustment, input level attenuation, RF power, auto off, key
lock.
RF Stability:
<±10kHz@Fc
Modulation Frequency Shift:
Wideband FM
±48kHz deviation
Harmonic Radiation:
<
-50dBc
Input Jack:
4
-pin mini jack
Battery:
2 x AA alkaline battery or NiMH rechargeable battery
Charging contacts:
Yes
Dimensions (without
antenna):
Height: 3.2 inch (81.5mm)
Width: 2.54 inch (64.5mm)
Depth: 0.98 inch (25mm)
