RE3-OL3 omnidirectional lavalier
Element Type:
Self
-biased Condenser
Frequency Response:
60Hz - 15 kHz
Polar Pattern:
Omnidirectional
Sensitivity: Open Circuit Voltage. 1
kHz:
17.5mV/Pascal
(
-35 dBV/PA)
Maximum SPL:
130dB SPL
Impedance:
2200 ohms
Power Requirements:
3-9 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage at
pin 2 relative to pin 1
Electrical Contact Pinouts:
Pin #1 - Ground, Shield
Pin #2
- Audio
Pin #3
- Bias Voltage
Dimensions (Cable length) :
57.1" [1450mm]
Dimensions (Head length) :
0.36" [9.2mm]
Dimensions (Head diameter) :
0.2" [5mm]
Microphone Connector:
4-pin mini plug
Head Finish:
Non-reflecting Black
Material:
Brass, Steel wire cloth grille, Black flexible PVC cable
RE3-CL3 cardioid lavalier
Element Type:
Self-biased Condenser
Frequency Response:
100Hz - 15 kHz
Polar Pattern:
Cardioid
Sensitivity: Open Circuit Voltage. 1
kHz:
20mV/Pascal
(-34 dBV/PA)
Maximum SPL:
115dB SPL
Impedance:
3700 ohms
Power Requirements:
3-9 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at pin 2 relative to pin 1
Electrical Contact Pinouts:
Pin #1 - Ground, Shield
Pin #2 - Audio
Pin #3 - Bias Voltage
Pin #4 - N/C
