Electro-Voice RE3 Series Installation Manual

62
en |
Technical data
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
Dimensions (Cable length) :
56.3" [1430mm]
Dimensions (Head length) :
1.04" [26.4mm]
Dimensions (Head diameter) :
0.4" [10.1mm]
Microphone Connector:
4-pin mini plug
Head Finish:
Non-reflecting Black
Material:
Die cast aluminum, Steel wire cloth grille, Black flexible
PVC cable
RE3-HW3 headworn microphone
Element Type:
Self-biased Condenser
Frequency Response:
30Hz - 18 kHz
Polar Pattern:
Supercardioid
Sensitivity: Open Circuit Voltage. 1
kHz:
0.5mV/Pascal
(-47 dBV/PA)
Maximum SPL:
130dB SPL
Impedance:
1000 ohms
Power Requirements:
3-9 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at pin 2 relative to pin 1
Electrical Contact Pinouts:
Pin #1 - Ground, Shield
Pin #2 - Audio
Pin #3 - Bias Voltage
Pin #4 - N/C
Dimensions (Cable length) :
45.28" [1150mm]
Dimensions (Boom length) :
5.83" [148mm]
Microphone Connector:
4-pin mini plug
Head Finish:
Non-reflecting Black
Material:
Black stainless steel painted adjustable headband frame.
Molded back facing connector joint with 2.5mm jack for
detachable cable, black textured PU. Black painted steel
100mm x 4.5mm flexible mic positing tube. Integrated
black TPR mic shock mount. Clear soft silicone tubing at
ear contact points.
