Electro-Voice RE3 Series Installation Manual

RE3
UHF Wireless Technical data | en 63
Electro
-Voice Installation manual 2018-12 | 01 |
F.01U.362.808
RE3-GC3 instrument cable
Electrical Contact Pinouts:
Pin #1 - Ground, Shield
Pin #2 - Audio
Pin #3 - N/C
Pin #4 - N/C
Connectors:
6.5mm (1/4 inch) phone plug
4-pin mini plug
Dimensions, Cable Length with
Connectors:
32.7” (830mm)
ND76-RC3 dynamic cardioid microphone head
Element Type:
Dynamic neodymium magnet structure
Frequency response, Close:
30 Hz – 17 kHz
Frequency response, Far:
70 Hz – 17 kHz
Polar Pattern:
Cardioid
Sensitivity, Open Circuit
Voltage @ 1 kHz:
5.6 mV/Pascal
(-45 dBV/Pa)
Maximum SPL:
135.5 dB SPL (1% THD)
Power Requirements:
4-8 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at center contact relative to ground contact
Electrical Contact:
3-Ring / 3-Pin
Threaded Coupling:
1.25” Diameter
28 UN-2A Thread Pitch
Finish:
Black polyurethane paint
Materials:
Aluminum, steel, steel wire grille screen
Dimensions, Length:
Diameter:
3.6 in (91 mm)
2.0 in (50.5 mm)
ND86-RC3 dynamic supercardioid microphone head
Element Type:
Dynamic neodymium magnet structure
Frequency response, Close:
30 Hz – 17 kHz
Frequency response, Far:
70 Hz – 17 kHz
Polar Pattern:
Supercardioid
Sensitivity, Open Circuit
5.6 mV/Pascal
