Electro-Voice RE3 Series Installation Manual

64
en |
Technical data
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
Voltage @ 1 kHz:
(-45 dBV/Pa)
Maximum SPL:
134.5 dB SPL (1% THD)
Power Requirements:
4-8 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at center contact relative to ground contact
Electrical Contact:
3-Ring / 3-Pin
Threaded Coupling:
1.25” Diameter
28 UN-2A Thread Pitch
Finish:
Black polyurethane paint
Materials:
Aluminum, steel, steel wire grille screen
Dimensions, Length:
Diameter:
3.6 in (91 mm)
2.0 in (50.5 mm)
ND96-RC3 dynamic supercardioid microphone head
Element Type:
Dynamic neodymium magnet structure
Frequency response, Close:
30 Hz – 15 kHz
Frequency response, Far:
140 Hz – 15 kHz
Polar Pattern:
Supercardioid
Sensitivity, Open Circuit
Voltage @ 1 kHz in flat position:
4.7 mV/Pascal
(-46.5 dBV/Pa)
Sensitivity, Open Circuit
Voltage @ 1 kHz in vocal presence
position:
3.2 mV/Pascal
(-50 dBV/Pa)
Maximum SPL:
136.5 dB SPL (1@ THD)
Power Requirements:
4-8 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at center contact relative to ground contact
Electrical Contact:
3-Ring / 3-Pin
Threaded Coupling:
1.25” Diameter
28 UN-2A Thread Pitch
Finish:
Black polyurethane paint
Materials:
Aluminum, steel, steel wire grille screen
Dimensions, Length:
Diameter:
3.3 in (83.5 mm)
2.0 in (50.5 mm)
RE420-RC3 condenser cardioid microphone head
