Electro-Voice RE3 Series Installation Manual

RE3
UHF Wireless Technical data | en 65
Electro
-Voice Installation manual 2018-12 | 01 |
F.01U.362.808
Element Type:
Self-biased Condenser
Frequency Response:
50 Hz to 20,000 Hz
Polar Pattern:
Cardioid
Sensitivity: Open Circuit Voltage. 1
kHz:
5.6mV/Pascal
(-45 dBV/PA)
Clipping (max SPL) :
137 dB SPL (1% THD)
Self Noise:
22 dB SPL "A" weighted (0 dB = 20 micropascals)
Dynamic Range:
115 dB
Signal-to-Noise Ratio:
72 dB
Power Requirements:
4-8 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage
at center contact relative to ground contact
Electrical Contact:
3-Ring / 3-Pin
Threaded
Coupling:
1.25” Diameter
28 UN-2A Thread Pitch
Finish:
Black polyurethane paint
Materials:
Aluminum, steel, steel wire grille screen
Dimensions, Length:
Diameter
:
3.36 in (85.3 mm)
1.95 in (49.6 mm)
