Sx80 175-Watt Two-Way Speaker System
Sx80 175-Watt Two-Way Speaker System
6
Figure 6— Sx80 Impedance Curve
Figure 5—Sx80 Harmonic Distortion
Response 10% Rated Power Input (17.5
watts), (full-space anechoic environ-
ment, 3.05 meters (10 feet) on axis)
Figure 4— Sx80 Directivity vs.
Frequency (full-space anechoic
environment)
