42
NetMax N8000 System Controller
Owner’s manual / Bedienungsanleitung
SIGNAL PROCESSING
Sample Rate 48 kHz internal
32 kHz - 192 kHz external
Data Format 24 Bit linear A/D and D/A conversion, 48 Bit processing
Signal Processing 2 DSPs Standard (150 MHz, 300 MIPS)
1 DSP per Audio Module (100 MHz, 100 MIPS)
DSP-1 Extension Module optional (+300 MIPS)
INTERFACES
Ethernet 10 / 100 MBit/s, RJ-45 (PC Control)
CAN 10... 500 kbit/s, 2 x RJ-45 (Remote Amp Control)
RS-232 2 Ports, 9pin D-Sub female (Remote Control)
USB USB Type B on Front Panel (PC Control)
GPIO Control Port 2 x 6-pole Euro block
4 Control Inputs (analog 0 - 10 V / logic control)
3 Control Outputs (Relay contact to ground)
1 Fault Output (NC Relay contact)
3 Reference Outputs (+5 V / +10 V / GND)
N8000 GENERAL SPECIFICATIONS
Power Supply 100 - 240 V AC, 50/60 Hz
Power Consumption 90 W max. (incl. 2 x AI-1, 2 x AO-1, 1 x CM-1 modules)
Safety Class I
Cooling Left-to-right, 3-stage fan
Operating Temperature Range 0 °C ... 40 °C
Dimensions (W x H x D) 483 x 88.1 x 381 mm (19“, 2 HU)
Weight N8000 (without optional modules): 7.35 kg
AI-1 Analog Input Module: 200 g
AO-1 Analog Output Module: 260 g
CM-1 CobraNet™ Module: 75 g
MODULES / OPTIONS
AI-1 Analog Input Module 8 analog audio inputs, line level, electronically balanced
AO-1 Analog Output Module 8 analog audio outputs, line level, electronically balanced
CM-1 CobraNet™ Module 32 digital audio inputs and outputs, 2 CobraNet™ ports
(Primary / Secondary) for network redundancy
DSP-1 DSP Extension Module Internal DSP processing power and Delay-RAM extension,
300 MIPS, 256k x 24 SRAM
MI-1 Microphone Input Module 8 microphone inputs, programmable Gain and Phantom
Power, PAD for line level switching
DI-1 Digital Input Module 8 digital audio inputs, AES/EBU, S/PDIF and Optical for-
mats, sample rate converters for 32-192 kHz operation
