NetMax N8000 System Controller
Owner’s manual / Bedienungsanleitung
6.2 Block Diagram/Blockschaltbild
AUDIO CARDS
8 Channels
Analog I/O
Digital I/O
AUDIO CARDS
8 Channels
Analog I/O
Digital I/O
AUDIO CARDS
8 Channels
Analog I/O
Digital I/O
SIGNAL
PROCESSING
DELAY
SRAM
CLOCK
CIRCUIT
12.288 MHz
FLASH
(8 MByte)
SDRAM
(16 MByte)
AC
POWER
SUPPLY
100 - 240 V ~
REAL TIME
CLOCK &
Watchdog
AUDIO
SLOT 1
GPIO
4 Analog Inputs
3 Logic Outputs
1 Ready/Fault Out
FRONT PANEL
(LEDs)
Clocks (MCLK, WCLK)
24 Bit DSP Bus
FRAM
RS-232
Port 1
RS-232
Port 2
USB Device
Interface
Ethernet
Transceiver
RJ-45
USB-Controller
Ethernet-Controller
UART2
UART1
SPI
Watchdog
HOST CPU
SYSTEM
USB Port
(
Typ B)
9-pin D-SUB
Internal
Expansion
Slot
CAN
Host Bus
Audio Out (4x8 Channels)
Audio In (4x8 Channels)
9-pin D-SUB
AUDIO
SLOT 2
AUDIO
SLOT 3
AUDIO
SLOT 4
AUDIO NETWORK
PORT
12-pin
Phoenix
Remote CAN
Interface
2 x RJ-45
AUDIO MODULES
8 Channels
Analog I/O
Digital I/O
AUDIO NETWORK
MODULES
32 Inputs / 32 Outputs
SPI Bus
