Electrolux 65G - Page 18

18
TYPE BURNER INJECTORS NOMINAL REDUCED NOMINAL FEEDING
OF GAS POWER POWER POWER PRESSURE
1/100 mm kW kW m
3
/h g/h mbar
Triple-crown 136 3,5 1,20 0,333 -
Ultra-rapid 121 3,2 0,65 0,305 -
Rapid 119 3,0 0,65 0,286 - 20
Semi-rapid 96 2,0 0,45 0,190 -
Auxiliary 70 1,0 0,33 0,095 -
Triple-crown 93 3,5 1,20 - 252
Ultra-rapid 88 3,2 0,65 - 231
Rapid 86 2,8 0,65 - 201 28-30/37
Semi-rapid 71 2,0 0,45 - 144
Auxiliary 50 1,0 0,33 - 72
Triple-crown 235 3,2 1,20 0,666 -
Rapid 235 2,9 0,65 0,604 - 12,5
Semi-rapid 180 2,0 0,45 0,417 -
Auxiliary 134 1,1 0,33 0,229 -
NATURAL
GAS
(Methane)
Technical data
LIQUID
GAS
(But./Prop.)
Specifications for hob burners and injectors
Electric Oven Heating elements rating
Model Appliances Width 60 cm Appliances Width 90 cm
Bottom heating element 1,000 W 1,200 W
Top heating element 800 W 1,000 W
Electric Grill element 1,750 W 1,800 W
Oven Light 15 W 15 W
Turnspit 4 W 4 W
Oven Capacity 57 dm³ 49,2 dm³ (appliances with electric oven)
46 dm³ (appliances with gas oven)
TYPE BURNER INJECTORS NOMINAL REDUCED NOMINAL FEEDING
OF GAS POWER POWER POWER PRESSURE
1/100 mm kW kW mbar
m
3
/h g/h
Oven burner 116 3,0 1,0 0,286 - 20
Grill burner 111 2,5 - 0,238 -
Oven burner 82 3,0 1,0 - 216 28-30/37
Grill burner 74 2,3 - - 166
NATURAL
GAS
(Methane)
LIQUID
GAS
(But./Prop.)
Specifications for oven burners and injectors - Appliances width 90 cm
TYPE BURNER INJECTORS NOMINAL REDUCED NOMINAL FEEDING
OF GAS POWER POWER POWER PRESSURE
1/100 mm kW kW m
3
/h g/h mbar
Oven burner 114 2,7 1,1 0,257 - 20
Grill burner 111 2,5 - 0,238 -
Oven burner 83 2,7 1,1 - 195 28-30/37
Grill burner 80 2,5 - - 180
Oven burner 199 2,8 1,1 0,583 - 12,5
Grill burner 218 2,6 - 0,541 -
NATURAL
GAS
(Methane)
LIQUID
GAS
(But./Prop.)
Specifications for oven burners and injectors - Appliances width 60 cm
Electric Plate: Ø 180mm - 1500 W (Mod. 65 G - 1000 W)
Appliance Class 1 and Class 2, Sub-Class 1
Category: II 2H3+
(Appliance set for use with gas: LPG G30-31 28-30/37 mbar)
Voltage tension: 230 V ~ 50 Hz
Plates and oven burners don't need regulation of primary air. Appliances should be installed in compliance with the local regulations.
Whereas pressure regulators are provided for appliances, they should comply with the rules in force.
TOWN
GAS
TOWN
GAS
