INSTALLING THE APPLIANCE
23
9 Securely fix both anti-tilt brackets to the floor, using the fasteners provided. Locate the
brackets against the rear wall so that the outside edges are 600mm apart. Two
fasteners must be used on each bracket and the fasteners must suit the floor material.
Note: The splashback must be in contact with the rear wall for the feet to be engaged
in brackets.
If cooker cannot be located against rear wall, adjust anti-tilt brackets forward
accordingly.
10 Slide the cooker back into the anti-
tilt brackets, so that the splashback
rests against
rear wall.
11 Check for height and level of the
product. Pull the cooker forward,
adjust the levelling feet, and return
to final position.
12 Connect services and commission
the cooker (see commissioning
section).
13 Fit removable kick rail, or screw on
the kick panel.
