1. Remove the belt from the motor and
spin the motor pulley. Does the motor
spin freely?
2. Remove the belt from the unit and
spin the tub pulley. Does the tub spin
freely?
3. Disconnect the motor plug. Measure
resistance of motor windings by
measuring from pin 1 to pin 2, pin 1 to
pin 3, and pin 2 to pin 3. All readings
should measure between 4 to 6 ohms.
No. Replace the motor.
Yes. Go to step (3).
No. Check the tub bearings. If tub bearings
check good, check unit for obstruction
between tub and spin basket.
Yes. Go to step (3).
If readings are correct, replace the motor
control board.
If readings are incorrect, replace the motor.
