Electrolux Affinity - Page 66

Tests
Test 15
1. Check the wiring between the main
control board and the user interface
board.
If the wiring is defective, correct the wiring.
If the wiring checks good, and none of the
LED’s light, replace the use interface board.
If this does not correct the error, replace the
main control board.
Note: If only one of the LED’s will not light,
replace the user interface board.
Test 16
1. Does the unit shut down shortly after
coming on?
2. Does the water valve come on and then
shut off after a short period of time?
Then does the pump come on and shut
off, and then power to the unit shuts
off?
3. If nothing happens when the start
button is pushed, replace the main
control board.
Yes. Check wiring to the door lock switch. If
the wiring checks good, replace the door lock
switch.
No. Go to step (2).
Yes. Replace the door lock switch.
No. Go to step (3).
Test 17
1. Check the wiring between the main
control board and the motor control
board.
If the wiring checks good, replace the motor
control board.
