23
Maintenance
Wine Rack Removal/Installation
To remove the wine racks for cleaning:
1 Grasp the end of the wine rack, sliding it out and up.
2 Clean wine rack with a damp rag.
To insert the wine racks:
1 Position the wine rack above the shelf channel where
the rack is to be inserted. (See Figure 26.)
2 Slide the rack on the channel at an angle until the rack is
in the channel.
3 Continue sliding until the rack is all the way into the wine
cooler.
Bulb Replacement
To replace the light bulb in your wine cooler:
1 Remove the light housing cover by sliding the cover
towards the tab, swinging the end opposite of the tab
down and pulling down and away (see Figure 27).
2 Replace bulb with genuine Electrolux replacement.
3 Replace the light housing cover by inserting the tab
FIRST and pushing up the other end. You should hear a
snap/click.
UL302
Figure 26
Figure 27
TAB
2
3
1
UL30
