16
Built-In Installation
INSTALLING A BUILT-IN
Your Electrolux wine cooler has been designed for either free-standing or built-in
installation. When built-in, your wine cooler does not require additional air space
for top, sides or rear. However, the front grille must NOT be obstructed.
See Figure 18 for dimensions in inches and millimeters.
Unit Dimensions
Model Width Height
NONO
NONO
NO
TETE
TETE
TE
To ease unit installation and removal, it is recommended that the cabinet
rough opening dimensions be increased by at least 1/4" over the
dimensions given for your unit.
Depth
E24WC48E 34-1/8"23-15/16" 23-1/4"
Figure 18
23 - 15/16”
(60.6)
34 - 1/8”
(86.7)
FULL
RETRACT
HEIGHT
23 - 1/4”
(59.1)
21”
(53.3)
