Electrolux ECFI3668AS Installation Instructions

3
36” ELECTRIC RANGE INSTALLATION INSTRUCTIONS
Product Dimensions
1. Measurement B varies according to the model:
the minimum is obtained without the rear spacers
(see "Island installation") and the maximum is
obtained for traditional installation (slot-in
installation - with the rear spacers).
2. Measurement C refers to the open door.
WARNING
Tip Over Hazard
• A child or adult could tip the
range over and be killed.
• Install the anti-tip device on
the floor or wall as per the
installation instructions.
• Engage the range with the
anti-tip device as per the
installation instructions.
• Ensure the anti-tip device is re-engaged when
the range is moved.
• Do not operate the range without the anti-tip
device in place and engaged.
• Failure to follow these instructions can result in
death or serious burns to children and adults.
To check if the anti-tip bracket
is installed properly, use both
arms and grasp the back edge
of the range. Carefully attempt
to tilt the range forward. When
properly installed, the range
should not tilt forward.
Refer to the anti-tip bracket installation instructions
supplied with your range for proper installation.
A
912.4 mm 35 15/16"
B
1
min: 627 mm
max: 631 mm
min: 24 11/16"
max: 24 13/16”
C
2
1116 mm 43 15/16"
D
min: 903 mm
max: 929 mm
min: 35 9/16"
max: 36 9/16"

Electrolux ECFI3668AS Specifications

General

Style	freestanding
Color	stainless steel
Main Capacity	4.4 cu. ft.
Temperature Probe	yes
Convection	true dual; yes
Induction	yes
Number of Burners	5
Number of Racks	2
Control Type	knobs
Interior Light	yes
Remote Control	no
Wi-Fi	no
Convection Power	3, 380 watts
Fuel	induction
Voltage	240 volts
Current	50

Weight and Dimensions

Depth	24 13/16 inch
Height	36 6/19 inch
Width	35 15/16 inch
