General information
- Calling the Service Functions is similar with all designs or key arrangements.
- Always use the keys S1, S2, S3 and S4 independently from their program assignment depending on
the model.
-In service function mode, you can ALWAYS call the Pulse Wash function by using keys S2 and S3.
Use key S2 to modify setting.
- From works settings, Pulse Wash is always set to be active.
- If you deselect Pulse Wash the rot.speeds of the circul. pump are always increased to High Pulse
Speed. Water consumption slightly increases. Extension of time is possible depending on the
temperature.
Always applicable:
In order to call the totality of service functions always first press the function keys S1 and S3 prior to
switching the appliance on by means of ON/OFF switch S0!
Keep the keys pressed for about 4 seconds in order to activate the function. This procedure is
intentionally distinguished from those for the customer functions.
Calling the function Switch OFF Pulse Wash
1. Simultaneously press S2 and S3 and...
2. ...switch on the appliance with ON/OFF switch
S1. Keep keys S1 und S3 pressed simultaneously
until the 3 acknowledging LEDs LD1. LD2 und LD3
are flashing.
(Short-time illumination of LEDs is possible and does
not constitute any fault)
3. Simultaneously press S2 and S3 until the
acknowledging LED LD2 is flashing. LEDs LD1 and
LD3 will go dark. The End-LED indicates whether
Pulse Wash is activated or deactivated.
End-LED on = Pulse Wash on
End-LED off = Pulse Wash off.
Switching the Pulse Wash function on or off:
4./5. Any further activation of function key S2 will
switch the addition alternately on or off.
Abandoning the function
After the last activation of function key S2 you can
leave the special program as follows: After 60
seconds automatically all indications will go dark,
except for the LD0 of the ON/OFF key
or
you switch the appliance off by means of ON/OFF key
S0.
Saving the status settings
Immediately after each input of data, the currently
valid status will be saved.
8.1.4 Service function/ Disconnection Pulse Wash
