Introduction & Purpose
Chapter
1
CONTENTS:
Introduction & Purpose Chapter 1
User Interface – Introduction Chapter 2
EDW 1600 Chapter 3.1
EDW 1850 Chapter 3.2
EDW 1950 Chapter 3.3
EDW 2200 Chapter 3.4
EDW 3510 Chapter 3.5
EDW 4010 Chapter 3.6
Alarm Codes Chapter 4
Purpose:
Purpose of this document is to give a description of the error codes of the
DIVA2 electronics of the EDW1xxx-2G and EDW1xxx-2G-ADO as well as
the Global hydraulic electronics power board electronic family.
Abbreviations, Acronyms and Definitions
RTA Remaining time adaptation
MCF Machine Configuration File
NTC
PB100
DIVA2
MCB
ADO
Negative Temperature Coefficient resistor
New platform for dual BLDC machines (Global hydraulic)
Platform with single BLDC control in separate unit (MCB)
Motor Control Board (DIVA2)
Auto Door Opener
Document Revisions
Revision Date Description Author
V0.0 10/2015 Document creation Rui Almeida
V1.0 05/2017 New codes iB1 – iB4
introduced. ‘B’ displayed as
‘H’. Full error code shown to
user
Rui Almeida
V2.0 11/2017 Correction description of iF0.
Added new error codes for
ETB in i6x family
Rui Almeida
Electrical appliances must be serviced only
by qualified Service Engineers.
Always remove the plug from the power
socket before touching internal components.
