Electrolux EDW 1953 - Contents; Abbreviations, Acronyms and Definitions

Introduction & Purpose
Contents:
Introduction & Purpose Chapter 1
User Interface – Introduction Chapter 2
EDW 503 Chapter 3.1
EDW 1103 Chapter 3.2
EDW 1503 Chapter 3.3
EDW 1753 Chapter 3.3
EDW 1953 Chapter 3.4
EDW 4013 Chapter 3.5
EDW 4033 Chapter 3.5
Alarm Codes Chapter 4
Purpose:
Purpose of this document is to give a description of the error codes of the
DIVA2 electronics of the EDW1xxx-2G and EDW1xxx-2G-ADO as well as
the Global hydraulic electronics power boards PB100, PB200, PB201 and
PB300 electronic family.
Abbreviations, Acronyms and Definitions
RTA
Remaining time adaptation
MCF
Machine Configuration File
NTC
PB100
DIVA2
MCB
ADO
Negative Temperature Coefficient resistor
New platform for dual BLDC machines (Global hydraulic)
Platform with single BLDC control in separate unit (MCB)
Motor Control Board (DIVA2)
Auto Door Opener
Document Revisions
Revision
Date
Description
v0.0
03/2016
Document creation
V1.0 05/2017 New codes iB1 – iB4 introduced. ‘B’ displayed as
‘H’.Full error code shown to user
 Electrical appliances must be serviced
only by qualified Service Engineers.
 Always remove the plug from the
power socket before touching internal
components.
Technical Support – A.R. Chapter 1
599 79 76 - 53 REV 1.0
