19
Reversing Door
x 4
1
2
3
4
x 2
x 2
C) Reinstalling Door Assembly
1. Rotate the door and hang the upper hook
on the back of the hinge in the upper hole
of the front panel.
D) Reinstalling Latch Cover and Hole Plugs
1. Install door latch cover with screws
removed earlier.
E) Verify Reversed Door Operation
1. Test door for free, smooth swinging
operation and secure latching when
closed.
2. Plug in dryer and close the door. Start
a test cycle: drum should tumble until
door is pulled open or cycle is paused or
canceled.
2. Reinstall and tighten all four screws
removed earlier - two front screws fi rst,
then two side screws.
2. Insert plastic hole plugs removed earlier.
