Electrolux EL1GMS - Gproduct Description; General Description; Machine Overview

13
Model
EL3...
ZL3...
NL3...
VL3...
EL3G
ZL3G
NL3G
VL3G
ELA3W...
ZLA3W...
NLA3W...
VLA3WG
ELA3GWP
ELA3G...
ZLA3G...
VLA3G...
ELA3GTL
EL3PO-
WAG
ZLA3
ELA3G6
ELA3GTL6
Rinse cycle
water
consumption
l 3 3 3 3
3 [Only for
models
EL3PO-
WAG -
ZLA3]
3 [Only for
model
ELA3G6]
3 for cycle 1
4 for cycle 2
3.5 for cycle
3
3 for cycle 1
4 for cycle 2
3.5 for cycle 3
Boiler capacity
l 5.8 5.8 5.8 5.8 5.8 5.8
Tank capacity
l 33 33 33 33 33 33
Standard cycle
time with water
supply at 50℃.
sec.
120 - 180 120 - 180
120 - 180 75 - 180 - 120
90 - 120 -
240
75 - 180 - 120
90 - 180 [Only
for model
VLA3WG]
120 - 180 - 240
[Only for model
ELA3GMCD]
90 - 120 - 240
[Only for model
ELA3GTL6]
90 - 180 [Only
for model
VLA3G]
Legal noise level
Leq
2
dB(A) LpA: 63dB - KpA: 1.5dB
Protection rating
IPX4
Power supply cable
H07RN-F
1. If activated by software, coincidence of tank and boiler heating elements.
2. The noise emission values have been obtained according to EN ISO 11204.
G PRODUCT DESCRIPTION
G.1 General description
The appliance is suitable for washing glasses, cups, cutlery.
Under no circumstances it can be used for other applications
or ways not provided for in this manual.
This equipment has been created in order to ensure a better
work environment and cost efficiency.
These appliances are used in restaurants, cafeterias, cooking
centers and large institutions. The special dish racks, that can
be equipped with various inserts, offer practical and easy use
for obtaining excellent washing results.
The electronic system enables complete supervision of the
washing process. The control panel also has a display that
shows the operating parameters and signals any faults.
G.2 Machine overview
1 Door
2 Control panel
3 Upper rinse arm
4 Upper washer arm
5 Lower washer arm
6 Lower rinse arm
7
Flat filters
8 Overflow
9 Wash tank filter
1
2
3
5
4
11
6
8
9
10
7
7
