EN Publication number
Nr
Rev. xx Month/year PR - 19/37
19
HBTN
Telescope tube
Bent end
Nozzle
Remove the screw using a torx
screwdriver
Detach the top cover
Remove 3 screws using a fine-cross
screwdriver
Remove the screw using a torx
screwdriver
Detach the complete brush lever
system
