3.10 Pressure switch PCB
The pressure switch PCB is only used on the RF controlled version. The 2 pressure switches are not
assembled.
For level 2, RF version, the RF receiver PCB and the RF antenna is assembled on this PCB.
ATTENTION:
Boards and electronic devices could be
damaged by electrostatic discharges.
Don’t touch any components without any
ESD protection.
