Electrolux EOE7C31X - Control Panel; Electronic Programmer

3. PRODUCT DESCRIPTION
3.1 General overview
8
6
7
5
4
1
2
3
21
5
4
3
1
Control panel
2
Electronic programmer
3
Socket for the core temperature
sensor
4
Heating element
5
Lamp
6
Fan
7
Shelf support, removable
8
Shelf positions
3.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
• Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
• Core temperature sensor
To measure how far the food is
cooked.
• Telescopic runners
For shelves and trays.
4. CONTROL PANEL
4.1 Electronic programmer
1 112 3 4 65 7 8 9 10
Use the sensor fields to operate the appliance.
Sensor
Field
Function Description
1
ON / OFF To turn the oven on and off.
2
OPTIONS To set a heating function, a cleaning function
or an automatic programme.
ENGLISH 7
