Electrolux EQBL100AS - Gas Requirements; Setting up the Barbecue; Fitting the Slimline Lid or Roasting Hood

8 gas requirements/setting up the barbecue/fitting the lid or hood electrolux integrated barbecue
Natural Gas requirements
• Theenclosuremustbeconstructedsothataccesscan
be gained to the Natural Gas regulator at all times.
• ForNaturalGasthegassupplyisrequiredtobe
connected to 1.2m flexible hose supplied and therefore
must be located within this distance
• Theexiblehosehasaquickconnectgascoupling.
The corresponding mating fitting will be required at the
gas supply end.
• ForpipesizingrequirementsforsupplypiperefertoAS5601.
Universal LPG Requirements
warning
• IfanLPGbottleistobestoredintheenclosureunder
the barbecue unit, it must be isolated from the barbecue
unit with a non-combustible panel. The enclosure must
comply with the requirements of AS5601.
• AS5601ventilationrequirementsforcylinderstorageare:
Where of sheet metal or similar impervious construction
there shall be ventilation openings at the top and
bottom of the enclosure or recess, each opening
providing a free area of at least 200cm
2
for every
cylinder enclosed.
Setting up the barbecue in mounting enclosure
• Amatchholderwithattachedchainhasbeenincluded
with the instruction manual. This is provided for manual
ignition in the event the automatic ignition does not work.
The free end of chain is required to be permanently
fixed to the installation in a location that enables the
match holder to reach each burner (refer to page 9 for
manual lighting instructions).
• Aftertheenclosurehasbeenconstructedasdescribed
on page 6, position the assembled barbecue into the
cut-out hole.
• Checkthatthebarbecueislevelandisrmlysupported.
When barbecue is level hotplate and grills will slope
downwards towards front for drainage.
• Connecttogassupply(UniversalLPGorNaturalGas)
and leak test.
• Fortmentoftheslimlinelidorroastinghood(seeright).
Gas requirements
Setting up the barbecue
Fitting of slimline lid
• Unpacktheslimlinelid.
• Removesidescrewsfrombarbecuetrimsurroundusing
allen key supplied.
• Fitbracketstotrimsurroundwiththesamescrews.
• Fitlidtobrackets.
Fitting of roasting hood
• Unpacktheroastinghood.
• Removesideandrearscrewsfrombarbecuetrim
surround using allen key supplied.
important
• Duetothesizeoftheroastinghood,itisrecommended
that two people place the roasting hood into position.
• Whenttingroastinghoodassembly,takeparticular
care to avoid scratching of the external trim.
• Onceinposition,xhoodassemblytotrimsurround
with same screws.
Fitting the slimline lid or roasting hood
210mm
non-combustible barrier
required under barbecue
at least 30mm clearance between
bottom of barbecue and barrier
cut hole in non- combustible
barrier for hose only
front of enclosure removed
for clarity
