Tech Sheet – Laundry Center FFL(E/G)3911/4033 GD000006035-B
Page 3 of 11
NOTE
The machine configuration for electrical test mode at the next power on after diagnostic mode, is not
active. So it is not necessary to power off the machine again.
1 User Interface Test
Selector position: Position 0, 12 o’clock, top center, the normal wash position
Purpose of test: Function of switches and buzzer.
Activated components: Buzzer with a switch change
UI behaviour Change switch positions and the buzzer beeps
Working conditions: Drum stopped, door unlocked
2 Hot Water Valve Test
Selector position: Turn 1 click clockwise from the top.
Purpose of test: Water loading from the hot water valve.
Activated components: Door lock, hot water valve, clutch motor
UI behaviour None
Working conditions:
Door locked, water level lower then 140mm, for max. 5 minutes. The clutch
moves to the agitate position, if it was in spin.
3 Cold Water Valve Test
Selector position: Turn 2 clicks clockwise from the top.
Purpose of test: Water loading from the cold water valve.
Activated components: Door lock and cold water valve, clutch actuator
UI behaviour None
Working conditions:
Door locked, water level lower then 140mm, for max. 5 minutes. The clutch
moves to the agitate position, if it was in spin.
4 Door Lid Unlock Test
Selector position: Turn 3 clicks clockwise from the top.
Purpose of test: Deactivate the door lock.
Activated components: Door lock.
UI behaviour None
Working conditions: Drum stopped
