Tech Sheet – Laundry Center FFL(E/G)3911/4033 GD000006035-B
Page 4 of 11
5 Three Water Valves Test
Selector position: Turn 4 clicks clockwise from the top.
Purpose of test: To test both hot and cold and, if present, softener water valves and the
softener siphon drains fully, agitate function.
Activated components: Door lock, three water valves, main motor
UI behaviour None
Working conditions: Door locked, Add while water level lower than 55mm, for max. 5 minutes.
The clutch moves to the agitate position, if it was in spin. Agitate begins
6 Drain and Clutch Test
Selector position: Turn 5 clicks clockwise from the top.
Purpose of test: Drain system with the clutch mechanism
Activated components: Door lock, drain pump, clutch actuator
UI behaviour None
Working conditions: Door locked, drum stop, run clutch to spin mode and drain until empty +10
seconds more. Run clutch actuator for about 100 seconds
7 Drain and Spin Test
Selector position: Turn 6 clicks clockwise from the top.
Purpose of test: Verify drain system, and Pressure Sensor calibration procedure
Activated components: Door lock, main motor, drain pump.
UI behaviour None
Working conditions:
Door locked, empty tub water level <5mm, if not the drain will run, if not in
spin mode the clutch actuator will run to spin position, spin up to maximum
speed.
8 Alarm History Test
Selector position: Turn 7 clicks clockwise from the top.
Purpose of test: Communicate alarm history
Activated components: Buzzer
UI behaviour A series of beeps separated by a short pause for one character and a long
pause to move to the second
character. Press selector for next stored
Working conditions: Drum stopped, Door unlocked
