Electrolux HSG Panini - Troubleshooting: Panino Overcooked on Top; Troubleshooting: Panino Sticks to Upper Plate; Troubleshooting: Panino Pressed Too Much

18/38
Problem Check if … If not, action to do
the resistor wiring 51 and 52 is
connected and not damaged (re-
sistor to terminal block and terminal
block to board)
reconnect or replace if damaged
The value of the resistance of the
probe is approximately 1,1KOhm at
room temperature (1,074 Kohm at
25°C/77°F)
replace the probe
the top heating element is absor-
bing current with the Multimeter
(approx. 4amps)
replace it
the board is providing the right vol-
tage : 208V for US version and 230V
for CE version
replace it
Panini is overcooked on the top
the top surface is cleaned (no
carbon deposits)
clean it
the right program was chosen use the right one
the programs have the right para-
meters
set the right parameters see the
brief cooking result trouble shooting
The value of the resistance of the
probe is approximately 1,1KOhm at
room temperature (1,074 Kohm at
25°C/77°F)
replace the probe
Panino sticks to the upper plate
The Panino is partially or
completely sticking to the upper
plate
the upper plate or the used baking
paper is clean
clean it
the upper plate or the used baking
paper is damaged
replace the baking paper or if neces-
sary the total upper plate kit
the programs have the right para-
meters (T<250°C)
set the right parameters see the
brief cooking result trouble shooting
the load (Panino) is appropriate to
the HSG
avoid this type of load
The panino is too much pressed
The Panino too much pressed
the upper plate can adjust to the
Panino automatically (free move-
ment)
deblock the upper plate by cleaning
and/or repairing
the Panino was placed correctly in
the work zone
train the user
the programs have the right para-
meters (time of MW)
set the right parameters
the load (Panino) is appropriate to
the HSG
avoid this type of load
The upper plate is not remova-
ble for cleaning
Upper plate not releasable
the release pin is blocked, so no
pushing possible
unblock the release pin
the release pin can not be pushed
enough to release the plate
readjust or replace the release
system
HSPP tech GB 03 09
No
Yes
Yes: Check ...
No
No
Yes
Yes: Check ...
No
No
No
Yes
Yes: Check ...
