Guide to diagnostics of EWX11831 electronic controls
2013 TS/DT-mdm FCPD-dp
30/71
599 77 00-82 Rev. 01
Drain the water from the tub.
Are the pressure switch tube and
pressure chamber unobstructed?
(disconnect the tubes and blow into them
to make sure the system is unobstructed)
–(see fig.2 and 8)-
E35
E35: Water level too high
E35
The main circuit board measures a water level, using the electronic pressure
switch, of more than 300 mm for longer than 15 secs.
Checks to perform:
\\\
Clean/change the tube and/or the
pressure chamber and repeat the
diagnostic cycle completely to check for
any further alarms.
Replace
the water fill
solenoid valve
and repeat the
diagnostic cycle
to check for any
further alarms.
Run the
diagnostic cycle
at phase 9.
Once the door
has locked, does
the appliance
start to fill with
water?
Replace the
analogue
pressure switch.
Run a rinse
cycle. Does the
E35 alarm
appear again?
Is the wiring
between the main
circuit board and
the analogue
pressure switch
connected
correctly on both
sides?
Replace the main
circuit board and
repeat the
diagnostic cycle
to check for any
further alarms.
Does the
appliance continue
to fill with water
even when it is
switched off?
Reconnect
and/or replace
the wiring and
repeat the
diagnostic cycle
to check for any
further alarms.
NO
NO
NO
NO
Fig. 2
Fig. 8
Check that all the connectors are correctly inserted
!
If there are burns on the circuit board,
see
a
e 69
!
NO
Repeat the
diagnostic cycle
to check for any
further alarms.
Replace the solenoid valve.
Repeat the diagnostic cycle to check for any
further alarms.
Y
E
Y
E
S
Y
E
Y
E
Y
E
