Page 3 KSSSI116
9. Safe Electrical Working Practices: refer to Page 55.
10. Positive Lock Terminals: refer to Page 56.
11. Capacitor Discharge: refer to Page 57.
12. Troubleshooting: refer to Pages 58 to 109.
Indoor & Outdoor Unit Error Code Display index.
LED Flash Code Sequence Description (Indoor & Outdoor)
Diagnostic Display Mode Description.
Fault Code, Condition Code & Test State Description/Solution.
13. Wiring Diagrams: refer to Pages 110 to 116.
Indoor Wiring Diagrams.
Outdoor Wiring Diagrams.
14. Temperature Sensors: refer to Pages 117 to 119.
Resistance Values in Accordance to Temperature.
15. Disassembly: refer to Pages 120 to 131.
16. DRED Installation Location: refer to Page 132.
17. Sizing Chart: refer to Page 133.
