Electrolux MCC4060E - Oven Schematic - Dual Cooking (Microwave;Convection); Oven Schematic - Dual Cooking (Microwave;Grill)

SOI 12.06 FV 42/43 599 37 42-75
SCHEMATICS
Figure O-5(a) Oven Schematic-Dual cooking Condition (Microwave and Convection).
Figure O-5(b) Oven Schematic-Dual cooking Condition (Microwave and Grill).
SCHEMATIC
NOTE:CONDITION OF OVEN
1. DOOR CLOSED
2. COOKING TIME ENTERED.
3. DUAL MODE PAD TOUCHED ONCE.
4. CONVECTION TEMPERATURE SELECTED.
5. MICROWAVE POWER LEVEL SELECTED.
6. START KEY TOUCHED.
SCHEMATIC
NOTE:CONDITION OF OVEN
1. DOOR CLOSED
2. COOKING TIME ENTERED.
3. DUAL MODE PAD TOUCHED TWICE.
4. MICROWAVE POWER LEVEL SELECTED.
5. START KEY TOUCHED.
TC2 : GRILL THERMAL
CUT
-
OFF
SW1 : MONITORED LATCH SWITCH
TC1 : MAG THERMAL
CUT
-
OFF
NOISE SUPRESSION COIL
EARTH
THERMISTOR
SW4:
DAMPER
SWITCH
SW2:
STOP
SWITCH
CONTROL
UNIT
T/C TRANSFORMER
NOISE FILTER
F2:FUSE
F8A
TC3: CONV. THERMO
CUT
-
OUT
LIVE
NEUTRAL
DAMPER MOTOR
CONVECTION MOTOR
FAN MOTOR
TURNTABLE MOTOR
CH: CONVECTION HEATING ELEMENT
GH: GRILL HEATING ELEMENTS
C: CAPACITOR
H.V. RECTIFIER
OVEN LAMP
SW3: MONITOR
SWITCH
ASYMMETRIC
RECTIFIER
T: HIGH VOLTAGE TRAN
S
F
O
RMER
F1: FUSE 20A
TC2 : GRILL THERMAL
CUT
-
OFF
SW1 : MONITORED LATC H SWITCH
TC1 : MAG THERMAL
CUT
-
OFF
NOISE SUPRESSION COIL
EARTH
THERMISTOR
SW4:
DAMPER
SWITCH
SW2:
STOP
SWITCH
CONTROL
UNIT
T/C TRANSFORMER
NOISE FILTER
F2:FUSE
F8A
TC3: CONV. THERMO
CUT
-
OUT
LIVE NEUTRAL
DAMPER MOTOR
CONVECTION MOTOR
FAN MOTOR
TURNTABLE MOTOR
CH: CONVECTION HEATING ELEMENT
GH: GRILL HEATING ELEMENTS
C: CAPACITOR
H.V. RECTIFIER
OVEN LAMP
SW3: MONITOR
SWITCH
ASYMMETRIC
RECTIFIER
T: HIGH VOLTAGE TRAN
S
F
O
RMER
F1: FUSE 20A
Note:
AC CORD CONNECTION
BRN: BROWN
BLU: BLUE
G-Y: GREEN AND YELLOW STRIPE
/15: SECTION AREA OF 1.5mm
2
MIN.
“” Indicates components with potential
above 250V.
