Description
Usage of the connections
It is possible to connect following features to the PCB:
P1 Fan motor/Drum motor
P2 Overheating protection and vacuum
P3 110 V AC in
P4 110 V AC out
P5 Heating system
P6 External ELS network
P7 Internal ELS network
P8 18 V AC out
P9 18 V AC in
P10 RMC
P11 RS 232 – internal use (incl. 24 V DC)
P12 RS 232 - program (external)
P13 Data bus (incl. 24 V DC)
P14 Data bus (incl. 24 V DC)
P15 Gas control
P16 Knob (Compass Control)
P17 Display (Compass Control)
P18 Temperature sensor and filter input
P19 External gas reset and external service switch
P20 Price reduction and external error (optional)
P21 Free dry
P22 Slot meter and payment system
P23 Slot meter and payment system
