Electrolux T4530 - Group 9 - Setting Programs

36
Program
Factory
setting
Para-
meter /
group
Comments
9 01
Test output 0 01 00/01 01 = Heat on in 3 seconds
9 02 Test output 1 01 00/01 01 = Drum left active in 3 seconds
9 03 Test output 2 01 00/01 01 = External signal active in 3 seconds
9 04 Test output 3 01 00/01 01 = Fan active in 3 seconds
9 05 Test output 4 01 00/01 01 = Drum right active in 3 seconds
9 06 Test input 0 00 - 01 0/1 0/1 Control of door switch 0 = Open, 1 = closed
9 07 Test input 1 00 - 01 0/1 0/1 Control of vacuum switch 0 = Open, 1 = closed
9 08 Test input 2 00 - 01 0/1 0/1 Control of external switch 0 = Open, 1 = closed
9 09 Test input 3 00 - 01 0/1 0/1
Control of condensation filter switch 0 = Open, 1 = closed
9 10 Test input 4 00 - 01 0/1 0/1 Control of filter door switch 0 = Open, 1 = closed
9 11 Test input 5 00 - 01 0/1 0/1 Control of overheating 0 = OK, 1 = Error
9 12 Test input 6 00 - 01 0/1 0/1 Control of gas error inlet 0 = OK, 1 = Error
9 13 Test input 7 00 - 01 0/1 0/1 Control of motor 1 overheating 0 = OK, 1 = Error
9 14 Test input 8 00 - 01 0/1 0/1 Control of motor 2 overheating 0 = OK, 1 = Error
Designation Range Step
Group 9 - Setting programs
Adjustableparameters
Various tests
