Electrolux W3240H Service Manual

438 9144-61/03
07.45
3
2
2. Technical data
Service
Manual
Technical data
Physical features
Model types
Washer extractor W365H/ W375H W3105H W3130H W3180H W3240H W3300H
FOM71 CLS
Inner drum
Volume l 65 75 105 130 180 240 300
Diameter mm 520 520 595 650 725 795 795
Depth mm 315 365 360 390 435 485 610
Capacity, dry weight
Filling factor 1:10 kg 6,5 7,5 10,5 13 18 24 30
Filling factor 1:13 kg 5 5,8 8 10 13,8 18,5 23
Drum speed
Washing rpm 52 52 49 49 44 42 42
Extraction rpm 1100 1100 1025 980 930 890 820
G factor
Extraction 350 350 350 350 350 350 300
Dimensions
Width mm 720 720 830 910 970 1020 1020
Depth mm 690 690 705 785 870 915 1060
Height mm 1115 1115 1300 1325 1410 1445 1445
Service area,
recommended
On the sides mm 50 50 50 50 50 50 50
Behind mm 500 500 500 500 500 500 500
Weight
Net kg 144/195 159 201 267 350 400 509

Electrolux W3240H Specifications

General

Brand	Electrolux
Model	W3240H
Category	Washer
Language	English
