6
CUPBOARD DIMENSIONS
NOTE: All sizes are internal and measured in millimetres.
For ‘lettered’ dimensions refer to the table on page 5.
Panel A
(sides)
Dim B
100mm
Dim A
Dim A + Skirting height
Panel B
(back)
Dim A + Skirting height + board thickness
Dim C + 2x Board
thickness
Dim B
Dim C
Dim E
80mm
Panel D
(bottom)
Panel C
(top)
130mm
Dim C
Dim B
Dim H
Dim C + 2x Board
thickness
Dim E
50mm
Skirting
height
