5
A4 TECHNICAL DATA
Standard cycle time may vary should the inlet water temperature be different from that indicated above.
MODEL EHTAROW / ZHTAROW /
OHTAROW
EHTAROW60 / ZHTAROW60 /
OHTAROW60
Supply voltage:
• three-phase version V 400...415- 3N~ 220...240- 3~ N~
- convertible to V 220...240- 3~ 400...415- 3
- convertible to V 220...240- 1N~ (**) 220...240- 1N~ (**)
Frequency Hz 50 60
Max. power input (three-phase version) kW 15,9 15,9
Max. power input (single-phase version) kW 9,9 9,9
Boiler heating elements kW 6,0 + 6,0 (**) 6,0 + 6,0 (**)
Tank heating elements kW 3,0 3,0
Water supply pressure kPa [bar] 50...700 [0,5...7] 50...700 [0,5...7]
Water supply temperature °C 10 ... 60 10 ... 60
Water supply hardness °fH [°dH ] 14 [8] max 14 [8] max
Rinse cycle water consumption l 3,0 3,0
Boiler capacity l 12 12
Tank capacity l 42 42
Standard cycle time:
- Thermal label mode sec. 77-90-150 77-90-150
- High productivity mode sec. 54-90-150 54-90-150
Legal noise level dB(A) <68 <68
Protection rating IPX4 IPX4
Net weight kg 98 98
Power supply cable H07RN-F H07RN-F
Supply cord diameter (min - max value) mm 18-25 18-25
(**) = Reduce the power of the boiler from 12 kW to 6kW as shown in the circuit diagram.
Table 1
400..415 V 3N 220...240 V 3 220…240 V 1N
CSCSCS
9,9 kW - - - - 3X10 60 A 1P+N
15,9 kW 5X6 40 A 3P+N 4X10 60 A 3P - -
C = Power supply cable
S = On/Off switch
Table 2
