6. Before starting the installation make sure the unit will fit in the location you intend to install it without
obstructing the operation of any controls.
7. If this instrument is to replace an existing unit in the aircraft, it is the installer's responsibility to move or
replace any existing instruments or components in the aircraft.
2. Instrument Setup:
There are four small switches on the back of the Smart Analyzer used to program this unit for your aircraft.
Set the switches below using a ball point pen.
9.5
Installation Instructions 1. Important Information and Initial Check Out:
