SYNTH TRACK PARAMETERS
The following messages affect the synth track parameters. They are also sent when adjusting the knobs controlling the
parameters.
OSC 1 NRPN
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Pitch A 1 0 0-127 0-127
B 1 0-127 -
Detune C 1 2 0-127 -
Keytracking D 1 3 0-127 -
Level E 1 4 0-127 -
Waveform F 1 5 0-127 -
Sub Oscillator G 1 6 0-127 -
Pulsewidth H 1 7 0-127 -
PWM Speed I 1 0-127 -
PWM Depth J 1 9 0-127 -
OSC 1 CC
Parameter Encoder CC MSB CC LSB Data Range MSB Data Range LSB
Pitch A 16 48 0-127 0-127
B - - 0-127 -
Detune C - - 0-127 -
Keytracking D - - 0-127 -
Level E 69 - 0-127 -
Waveform F 70 - 0-127 -
Sub Oscillator G 71 - 0-127 -
Pulsewidth H 72 - 0-127 -
PWM Speed I 73 - 0-127 -
PWM Depth J 74 - 0-127 -
NOISE NRPN
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Noise S&H A 1 10 0-127 -
B 1 0-127 -
Noise Fade C 1 12 0-127 -
D 1 0-127 -
Noise Level E 1 14 0-127 -
F 1 0-127 -
G 1 0-127 -
H 1 0-127 -
I 1 0-127 -
J 1 0-127 -
