D-4 Appendix D: MIDI

OSC COMMON NRPN

Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB

OSC1 AM A 1 30 0-127 -

Sync Mode B 1 31 0-127 -

Sync Amount C 1 32 0-127 -

Bend Amount D 1 33 0-127 -

Slide Time E 1 34 0-127 -

OSC2 AM F 1 35 0-127 -

Note Sync G 1 36 0-127 -

Vibrato Fade H 1 37 0-127 -

Vibrato Speed I 1 38 0-127 -

Vibrato Depth J 1 39 0-127 -

OSC COMMON CC

Parameter Encoder CC MSB CC LSB Data Range MSB Data Range LSB

OSC1 AM A - - 0-127 -

Sync Mode B - - 0-127 -

Sync Amount C 84 - 0-127 -

Bend Amount D 85 - 0-127 -

Slide Time E 5 - 0-127 -

OSC2 AM F - - 0-127 -

Note Sync G - - 0-127 -

Vibrato Fade H - - 0-127 -

Vibrato Speed I 87 - 0-127 -

Vibrato Depth J 88 - 0-127 -

FILTERS NRPN

Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB

Filter1 Frequency A 1 40 0-127 0-127

Filter1 Resonance B 1 41 0-127 -

Filter Overdrive C 1 42 0-127 -

Filter1 Keytracking D 1 43 0-127 -

Filter1 Envelope Amount E 1 44 0-127 -

Filter2 Frequency F 1 45 0-127 0-127

Filter2 Resonance G 1 46 0-127 -

Filter2 Type H 1 47 0-127 -

Filter2 Keytracking I 1 48 0-127 -

Filter2 Envelope Amount J 1 49 0-127 -
