Appendix D: MIDI D-9
FX TRACK PARAMETERS
The following messages affect the FX track parameters. They are also sent when adjusting the knobs controlling the
parameters.
EXT IN
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Ch1 Chorus Send A 2 0 0-127 0-127
Ch1 Delay Send B 2 1 0-127 -
Ch1 Reverb Send C 2 2 0-127 -
Ch1 Pan D 2 3 0-127 -
Ch1 Level E 2 4 0-127 -
Ch2 Chorus Send F 2 5 0-127 -
Ch2 Delay Send G 2 6 0-127 -
Ch2 Reverb Send H 2 7 0-127 -
Ch2 Pan I 2 8 0-127 -
Ch2 Level J 2 9 0-127 -
CHORUS
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Predelay A 2 40 0-127 0-127
Speed B 2 41 0-127 -
Depth C 2 42 0-127 -
Width D 2 43 0-127 -
Feedback E 2 44 0-127 -
HP Filter F 2 45 0-127 -
LP Filter G 2 46 0-127 -
Delay Send H 2 47 0-127 -
Reverb Send I 2 48 0-127 -
Send Level J 2 49 0-127 -
DELAY
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Time A 2 50 0-127 0-127
Mode B 2 51 0-127 -
C 2 52 0-127 -
Width D 2 53 0-127 -
Feedback E 2 54 0-127 -
HP Filter F 2 55 0-127 -
LP Filter G 2 56 0-127 -
Overdrive H 2 57 0-127 -
Reverb Send I 2 58 0-127 -
Send Level J 2 59 0-127 -
