Appendix D: MIDI D-11
CV TRACK PARAMETERS
The following messages affect the CV track parameters. They are also sent when adjusting the knobs controlling the
parameters.
CV A
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
CV A Tune A 3 0 0-127 0-127
B 3 0-127 -
CV A Value C 3 2 0-127 -
CV A Clock D 3 3 0-127 -
CV A Source E 3 4 0-127 -
F 3 0-127 -
G 3 0-127 -
H 3 0-127 -
I 3 0-127 -
J 3 0-127 -
CV B
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
CV B Tune A 3 20 0-127 0-127
B 3 0-127 -
CV B Value C 3 22 0-127 -
CV B Clock D 3 23 0-127 -
CV B Source E 3 24 0-127 -
F 3 0-127 -
G 3 0-127 -
H 3 0-127 -
I 3 0-127 -
J 3 0-127 -
CV C
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
CV C Tune A 3 40 0-127 0-127
B 3 0-127 -
CV C Value C 3 42 0-127 -
CV C Clock D 3 43 0-127 -
CV C Source E 3 44 0-127 -
F 3 0-127 -
G 3 0-127 -
H 3 0-127 -
I 3 0-127 -
J 3 0-127 -
CV D
