Elektror RD 62 - Page 9

9
GB
IRL
Type RD 62 RD 64 RD 65
Item Designation Part no. Part no. Part no.
1 Blower housing 000657 001180 001887
2 Impeller clockwise for 50 Hz 000121 000503 000812
Impeller anti clockwise for 50 Hz 000122 000508 000856
Impeller clockwise for 60 Hz 000183 000186 000812
Impeller anti clockwise for 60 Hz 000185 000520 000856
3 Housing cover 000658 001276 000925
4 Wire mesh guard 000720 000720 000083
5 Blower base 001339 000235 000768
6 Blower flange 002012 001991 000953
7 Drive motor X X X
22 Washer 002375 002375 002375
Design with temperature barrier S 484
33 Spacer ring 004449 004449 004570
34 Ventilating fan 003672 003672 004446
Design with teflon radial shaft seal
40 Blower flange 002012 001991 000953
41 Teflon radial shaft seal 000817 000817 000818
Explantation of symbols: X required, – not required
The replacement parts list does not apply to explosion-proof
appliances and only to a limited extent to other special designs.
Only original replacement parts should be used.
