Element4 Sky - Installing the Fire Media; Logs

41
INSTALLING THE FIRE MEDIA
Element4 Gas Fireplaces EuropeanHome.com
LOG ARRANGEMENTS
Ensure that the hearth panel is sitting rmly in the base of the re box with the long slots in the center of the panel aligning with
the top of the burners. The pilot ame must be visible through the panel and the cut-out in the pilot shield. Scatter the bag of
embers on the hearth panel and burners as shown in Figure 34. Ensure that the area inside the ember shield (circled) is left clear.
Position the embers, coals and r cones as shown in Figure 34.
Position four of the larger logs as shown in Figure 35.
1
4
1
2
3
Figure 34
Figure 35
