ELEMENTI MODENO Nantucket - Assembly Instructions; Initial Setup: Battery and Tank Seat

9 / 20
ASSEMBLY INSTRUCTIONS
1
Make sure the gas supply system is turned to “OFF”.
Install the AAA battery as shown in the diagram below.
2
1
2
1. Place the tank seat on the ground and place a 20 lb. propane tank
into the tank seat.
2. Tighten down the screw on the side of the tank seat to secure the
propane tank.
20lbs
20lbs
+
